SD-X SNIPER EVO PRO FRONT HUB - 20MM 36H

he SD-X Sniper Evo Pro front hub is designed for riders who accept no limits. Developed to meet the highest demands of BMX racing, this hub delivers uncompromising strength, durability, and precision. Its lightweight aluminum construction, combined with SKF ABEC-5 bearings, ensures smooth rotation and long-term reliability.

The hub is supplied as standard in 20 mm version and can be converted to a 10 mm Pro hub using the Evo Pro Front Hub conversion kit available as an option. Please note that bolt caps and titanium bolts must be ordered separately for the 10 mm configuration.

Customize your hub with a wide selection of interchangeable parts and color options.

• Supplied in 20 mm configuration as standard
• Convertible to 10 mm using the Evo Pro Front Hub conversion kit (sold separately)
• SKF ABEC-5 bearings of high quality
• Hub shell and internal components made from premium 7075 aluminum
• Hub supplied without 20 mm axle

SPECIFICATIONS

• Material : 7075 Aluminum
  • Spacing : 20x100mm
• Hole count : 36
• Bearings : 6805
• Weight : 150g

• TECHNICAL INFO



  A : Total length : 100 mm
  B/C : Distance between flange and outer side : 14mm
  D/E : Flange diameter : 49mm
